QSFP is from a simple single-mode fiber SONET applications out into other multimode fiber applications, such as Gbps Ethernet, Fibre Channel, InfiniBand and so on. Many MSA members of the supply VCSEL chip, parallel VCSEL chips, pushing the QSFP technology in the field of multi-mode.

QSFP Active Optical Cable Product Features:

* Designed to meet the standard QSFP MSA
* Compatible with Infiniband QDR, DDR and SDR standard
* The use of VCSEL arrays and PD array standard 850nm wavelength
* 12-core OM3 multimode fiber
* High rate density: 4 hair 4 income, single-channel rates up to 11.5Gbps
* Low power consumption: single-ended power consumption less than 900mW
* Support Hot Swap
* Built-in digital diagnostic automation error correction
* 2.5Gbps transmission distance up to 500 meters, 11.5Gbps transmission distance up to 100 meters
* 0 ~ 70 ℃ ambient temperature normal operation

QSFP Active Optical Cable scenarios:

*data center
* Infiniband QDR (4 × 10G), DDR (4 × 5G) and SDR (4 × 2.5G)
* High-performance computer
* Network storage, routers and switches
* PCI-Express, SAS / SATA and fiber optic interconnection other occasions
