40GBASE-LR4 QSFP+ 1310nm 10km Transceiver Module for SMF

Payment:
Paypal or Credit/debit card
Wire Transfer, West Union | See details
Returns:
Satisfactory return or item exchange | See details
Guarantee:
Money back guarantee | See details
Warranty:
Limited Warranty | See details
Volume pricing:
If you need large order volume, please apply for a business account or contact us to enjoy preferential policies.
SKU#:QSFP-LR4
Price:

$2,390.00

$599.00

Quick Overview:
In Stock
40GBase-LR4, QDR, 1310nm, 10KM@SMF
Compatible Option ( Compatible with various Brands of Switches/HPC/NIC/CNA...)
Warranty: 1-Year
Qty:

40GBASE-LR4 QSFP+ 1310nm 10km Transceiver Module for SMF

  • 40GBASE-LR4 QSFP+ 1310nm 10km Transceiver Module for SMF
Processing Time
Processes in 24 hours: Processing Time is guaranteed to be shorter.
Typical Processing Time: 1-2 weeks
Shipping Time
FedEx Overnight: Within 1-4 business days
DHL: Within 2-6 business days
EMS: Within 4-15 business days
UPS: Within 2-5 business days
Hong Kong Post Airmail: Within 10-30 business days
Payment Methods
FiberOnSale FiberOnSale FiberOnSale
FiberOnSale Paypal western
Wire Transfer
40GBASE-LR4 QSFP+ 1310nm 10km Transceiver Module for SMF
10Gtek's QSFP+ transceiver modules are designed for use in 40 Gigabit?Ethernet links over single mode fiber. They are compliant with the QSFP+ MSA and IEEE 802.3ba 40GBASE-LR4. Digital diagnostics functions are available via an I2C interface, as specified by the QSFP+ MSA. The transceiver is RoHS-6 compliant and lead-free per Directive 2011/65/EU, and Application Note AN-2038.

10Gtek's QSFP-40G-LR4 Module supports link lengths of 10KM. It primarily enables high-bandwidth 40G optical links over ribbon fiber cables terminated with multi-fiber connectors, and could also be used along with ribbon to duplex fiber breakout cables for connectivity to four 10GBASE-LR optical interfaces. This QSFP-40G-LR4 is built according to Cisco specifications, and is 100% compatible with Cisco System.
Features:
  • 4 CWDM lanes MUX/DEMUX design
  • Up to 10km transmission on single mode fiber (SMF)
  • Up to 11.2Gbps data rate per wavelength
  • QSFP+ MSA compliant
  • Maximum 3.5W operation power
  • Operating case temperature: 0ºC~70ºC
  • RoHS-6 compliant
Applications:
  • 40G Ethernet
  • Infiniband interconnects
  • 40G Telecom connections
Order Information:
Part Number Description Data Rate Wavelength Reach Connector Fiber Type TX Power (dBm) Rx Sens. (dBm) Temp. Range(°C)
QSFP-SR4 QSFP+ SR4 44.8Gbps 850nm 150 m MTP/MPO MMF -7.6~1 < -9.5 0~70
QSFP-eSR4 QSFP+ eSR4 44.8Gbps 850nm 300 m MTP/MPO MMF -7.3~1 < -9.9 0~70
QSFP-IR4 PSM QSFP+ IR4 PSM 44.8Gbps 1310nm 1.4 km MTP/MPO SMF -5.5~1.5 < -11.5 0~70
QSFP-LR4 PSM QSFP+ LR4 PSM 44.8Gbps 1310nm 10 km MTP/MPO SMF -5.5~1.5 < -12.6 0~70
QSFP-IR4 QSFP+ IR4 44.8Gbps CWDM 2 km LC SMF -7~2.3 < -11.7 0~70
QSFP-LR4 QSFP+ LR4 44.8Gbps CWDM 10 km LC SMF -7~2.3 < -13.7 0~70
QSFP-ER4 QSFP+ ER4 44.8Gbps CWDM 30 km LC SMF -3.7~4.5 < -20.2 0~70
